Economy Double Leaf Height Restriction Barrier

The SB.23E is a reliable and robust height restriction barrier, offering an ideal solution to prevent unauthorized access by taller vehicles in areas like car parks, shopping centres, recreational grounds, and similar locations.

Our double-leaf gates are equipped with a heavy-duty sliding latch mechanism, centrally positioned to securely close both gates. Additionally, a padlock facility allows users to lock the gates with their chosen padlock for added security.

Each gate is supplied with galvanized, heavy-duty adjustable eyebolts, enabling precise alignment during installation.

We offer both sunken (concrete-in) and surface-mounted (bolt-down) fixture options to meet various needs, though we recommend concreting in for the most secure installation.

Gates can be secured in the open position with the purchase of latch-back posts, which are designed with a self-locking catch to prevent the gates from bouncing out of position. These posts also feature a padlock facility, allowing the gates to be locked in the open position when necessary.

Please note: Latch-back posts are manufactured to match the gate fixture type (concrete-in or bolt-down).

All barriers are available with a choice of finishes: powder-coated, galvanised, or a double finish (galvanised & powder-coated).

Please be advised that, as this product is made to order, you may need to confirm the sizing before manufacturing can begin.

Specifications

• Hinge Post: 100 x 100mm Box Section
• Latch Back Post: 100 x 100mm Box Section
• Barrier: 100 x 60 x 3mm Box Section
• Concrete-In Depth: 760mm Below Ground
• Bolt-Down: 18mm diameter holes (fixings not supplied)
• Central sliding latch with padlock facility
• Supplied with galvanized adjustable eyebolts
• Gate opens 180° (depending on hinge post positioning)
• Other powder coating colours available on request
• Signage will reflect the selected height (e.g., “Maximum Height 2.1 Meters” if 2.1 meters is selected)

Delivery Times

• Powder Coated Only: 7-14 working days
• Galvanized Only: 7-14 working days
• Double Finish (Galvanized & Powder Coated): 14-21 working days

Warranty Information

This product includes a standard 1-year warranty.
